Overview introduction:
Product name: computer wire cable cutting and stripping machine
Product overview
No.1 this machine is controlled by computer and operated by keys. It has stable performance
and easy operation;
No.2 high speed wire stripping, the head, tail and total length of wire can be set arbitrarily
within the range of wire cutting
No.3 can independently set wire feeding, tangent and stripping speed to meet the best
stripping effect;
No.4 has the functions of setting the total amount, number of wires, delay and intermediate
stripping;
No.5 motor drive adopts subdivision mode, with high precision and long service life;
No.6 can store 100 kinds of different specifications of wire processing data. .
Features:
Visual and clear display: Chinese- English switch, Easy to use, the screen displays all kinds of data
Microcomputer numerical control: Half peel / Middle multi clip, The control system can freely set the peeling at both ends
Made of steel knife: One knife for multiple purposes, High-speed steel material, a wide range of applications
Line roller adjustment: Easy to adjust. The force of the crimping wheel can be directly adjusted manually
Data Sheet
Wire diameter range | 0.1-6mm2 (special, customi |
Wire Range | PVC、PE、 |
Cut length | 5- 99999mm |
Length accuracy | 士(0.2%*L+1) mm |
Stripping Length | 0.5-30mm (special, customizable) |
Intermediate cutting and stripping | 1-13 |
yield | 3000-7000 pcs/h |
Blade material | Imported high speed steel and tungsten steel |
Driving mode | Four wheel drive |
Wire speed | 2m/s |
Power Supply | 220V 50HZ |
powe | 0.24KW |
weight | 28kg |
Dimensions | 420x 340x 280mm |
