Basic accessories of wire stripping machine

Views: 315     Author: Site Editor     Publish Time: 2021-12-15      Origin: Site Inquire

Basic accessories of wire stripping machine


Wire stripping machine is a specialized wire harness processing automation equipment in the industry. Its main function is to strip off the protective layer outside the wire. The wire stripping machine technology is widely used in audio and data wire prices and various wire harness processing industries. So do you know what are the basic accessories of the stripping machine? What role do they play in the wire stripping machine? Next, let's take a look at it in detail. Here are some answers.



主图06
主图03
主图04
主图05


Here is the content list:

  • Inlet and outlet reels

  • Six "knobs"

  • Tool holder assembly


Inlet and outlet reels

The wire feeding wheel conveys the wire and strips the wire end. When stripping short wires, the wire stripping machine has both the stripping head and the stripping tail (the length of the wire is less than 50mm). When stripping in the wire stripping machine, in addition to the stripping head, it also has the function of stripping the middle parts. The outgoing wheel is a wire stripping machine that conveys the wire and strips the wire tail. The industrial wire stripping machine has no effect when stripping short wires. It is necessary to make the "outlet wheel lift knob" at the "u" position.


Six "knobs"

First, the wire-in wheel gap adjustment knob adjusts the wire-in wheel gap of the wire stripping machine. Rotate upward to increase the gap, and rotate downward to decrease the gap (adjust according to the thickness of the wire). Second, the electronic wire stripping machine inlet wheel pressure adjustment knob adjusts the inlet wheel pressure of the wire stripping machine. After pulling it out, rotate it clockwise, the pressure of the inlet wheel will increase and rotate counterclockwise after pulling out, and the pressure of the inlet wheel will decrease. It is determined according to the strength of the wire sheath of the wire, that is, the difficulty of stripping the sheath, the more difficult the pressure increases, and the easier the pressure decreases. Third, the wire stripping machine raises the wire stripping machine when threading the wire. Turn the knob clockwise to raise the wire so that the wire can be passed smoothly; when working, lower the wire stripping machine and turn the knob counterclockwise to lower it. Into the wire wheel, press the wire.


Fourth, the outlet wheel gap adjustment knob is used for the wire stripping machine to adjust the outlet wheel gap. Rotate upward to increase the gap, and rotate downward to decrease the gap (adjust according to the thickness of the wire). Fifth, the outlet wheel pressure adjustment knob adjusts the outlet wheel pressure for the wire stripping machine. After pulling it out, it rotates counterclockwise and the outlet wheel pressure increases. After pulling it out, it rotates clockwise and the inlet wheel pressure decreases. It is determined according to the strength of the wire skin, that is, the difficulty of stripping the power wire stripping machine, the pressure increases, and the pressure decrease when it is easy. Sixth, the function of the outlet wheel lifting knob is to raise the outlet wheel when the wire is taken out. Turn the knob counterclockwise to raise the outlet wheel so that the wire can be taken out smoothly; lower the outlet wheel when working, and turn the knob clockwise to lower the outlet wheel. When using the short stripping program, the outlet wheel should be raised.


Tool holder assembly

The tool holder assembly is responsible for the cutting, stripping, and tailing of the wire in the wire stripping machine. When the machine is stopped, the upper and lower blades must be opened to the maximum so that the wire can pass through the cutter smoothly.
